NUNC 176740 4孔细胞培养板

NUNC（Thermo）176740 4 孔细胞培养板 中英文产品介绍

中文产品介绍

产品简介

Nunc™4 孔多孔细胞培养板（货号176740），Nunclon‑Delta TC 贴壁表面处理，透明聚苯乙烯，2×2 排布圆孔平底，配套定位通风盖板；γ 射线辐照灭菌（SAL 10⁻⁶），无热原、无 DNase/RNase、无细胞毒性。单孔培养面积1.9 cm²，推荐工作体积 1 mL / 孔，单孔最大容积 3.2 mL；4 块 / 小包，整箱 120 块；适配盖玻片（22×22 mm），兼容明场、荧光显微镜成像，适合贴壁细胞、原代细胞、免疫荧光成像实验Capitol Sc...。

• 货号：176740
• 孔型：4 孔，2×2 排布，平底圆孔
• 表面：Nunclon‑Delta TC 组织培养处理（贴壁细胞）
• 材质：透明聚苯乙烯 PS
• 单孔生长面积：1.9 cm²
• 推荐工作体积：1 mL / 孔；最大容积 3.2 mL / 孔
• 灭菌：γ 辐照无菌 SAL 10⁻⁶
• 包装：4 块 / 包；120 块 / 箱
• 外形尺寸：66 mm × 66 mmCapitol Sc...

主要特点

1. Nunclon‑Delta 亲水 TC 改性表面，提升贴壁细胞、原代细胞粘附，批次稳定性好，实验重复性高Thermo Fis...。
2. 孔周凸起围堰，降低孔间交叉污染；盖板带通风间隙保障 CO₂气体交换；盖板定位切角，防止盖板放反；板与盖板带有书写标记区，孔位带字母‑数字编号，便于样本追踪；孔周边储水凹槽，减少培养基蒸发损耗Capitol Sc...。
3. 光学级高透明平底，可直接放入方形盖玻片，特别适合免疫荧光、细胞染色成像观察；板体小巧，培养箱堆叠放置稳固。
4. γ 辐照无菌，无热原；独立小包分装，避免耗材污染。
5. 一次性耗材，禁止高压灭菌重复使用。

⚠️提示：176740 为 TC 贴壁处理圆孔 4 孔板；悬浮细胞选用未处理货号179820；矩形大孔 4 孔板货号 167063，不要混淆Thermo Fis...。

下游应用

贴壁细胞培养；原代细胞成像；免疫荧光染色；盖玻片细胞爬片；药物处理后荧光观测；小规模细胞学功能实验。

储存条件

室温干燥避光保存；一次性使用，不可高压灭菌。

English Product Introduction

Product Description

Nunc™ 4‑well multidish (Cat.No.176740), Nunclon‑Delta tissue‑culture‑treated surface, clear polystyrene, 2×2 array of round flat‑bottom wells with oriented ventilated lid. Gamma‑irradiated sterile (SAL 10⁻⁶), non‑pyrogenic, DNase‑/RNase‑free and non‑cytotoxic. Growth area per well: 1.9 cm², recommended working volume 1 mL per well, maximum volume 3.2 mL per well. Pack:4 plates/pouch, total 120 plates per case. Compatible with standard 22×22 mm coverslips, suitable for bright‑field and fluorescence microscopy for adherent and primary‑cell experimentsCapitol Sc...。

• Catalog No.: 176740
• Well format:4‑well,2×2 array, round flat‑bottom wells
• Surface treatment: Nunclon‑Delta TC‑treated (for adherent cells)
• Material: Clear polystyrene (PS)
• Growth area per well:1.9 cm²
• Recommended working volume:1 mL/well; maximum volume 3.2 mL/well
• Sterilization: Gamma‑irradiation (SAL 10⁻⁶)
• Packaging:4 plates per pouch;120 plates per case
• Outer dimension:66 mm × 66 mmCapitol Sc...

Key Features

1. Nunclon‑Delta hydrophilic TC surface improves adhesion of adherent and primary cells and ensures reliable batch‑to‑batch reproducibilityThermo Fis....
2. Raised well rims minimize cross‑well contamination. Ventilated lid ensures sufficient gas‑exchange inside CO₂ incubator; orientation notch prevents lid mis‑placement. Writing zones on plate and lid; alphanumeric well identifiers for sample tracking; peripheral reservoir groove reduces medium evaporationCapitol Sc....
3. High‑clarity optical flat bottom compatible with standard coverslips, optimized for immunofluorescence staining and cell imaging. Compact footprint enables stable stacking inside incubator.
4. Gamma‑irradiated sterile and non‑pyrogenic. Packaged in small pouches to avoid contamination of unused plates.
5. Single‑use consumable. Do not autoclave.

Note: Cat.No.176740 is TC‑treated round‑well plate for adherent cells. Use non‑treated Cat.No.179820 for suspension‑cell culture. Rectangular large‑well 4‑well plate: Cat.No.167063Thermo Fis....

Applications

Adherent cell culture; primary‑cell imaging; immunofluorescence staining; coverslip cell slide preparation; fluorescence observation after drug treatment; small‑scale cellular functional assays.

Storage

Store at room‑temperature in dry, dark environment. Single‑use only, autoclaving prohibited.
