- 保修期：
1年
| Features |
|
|
|
| Application | |
|
|
| Description | |
| Frequency meter is intended for measuring frequency in range 70-330GHz.The Frequency Meter is based on sweepable heterodyne receiver. Fully outomated system allows to measure frequency without preslection frequency range.This solution is ideal for laboratory test measurement. |
|
Specifications
| Input Frequency range | 70 – 330 GHz |
| Maximum input | + 10 dBm |
| Minimum input | -20 dBm |
| Damage level | +13 dBm |
| Dynamic range | 30 dB |
| Standard Input connectors | Flange UG-378/U-M |
| Standard Input waveguide | WR-10 |
| Standard Output connector | SMA |
| Modes of operation | Counter |
| Accuracy | +/- 1 MHz |
| Resolution | 1 kHz |
| IF Output | 50-100 MHz |
| Control Interface | GPIB |
| Power Supply | 230 V, +/- 10%, 50- 60 HZ,~200 VA |
| Operating temperature range | +10°C…+ 50°C |
